How to choose the right long fork pallet trucks

Long fork pallet trucks make it easier to move long goods, non-standard pallets and multiple pallets at once. While the standard-length hand pallet truck fork length is 1150 mm, our extra-long pallet jack fork lengths range from 1207 to 2500 mm. They offer more reach than a standard hand pallet truck while remaining manoeuvrable for warehouses and workplace transport.

At Jungheinrich PROFISHOP you can buy these models from trusted brands including Jungheinrich and Ameise®, with different fork lengths, load capacities and features to suit your operation

1. Choose the right fork length and width for your long fork pallet truck

Product image no. 6: Jungheinrich AM 22 hand pallet truck, load capacity 2,200 kg, fork length 1,207 mm, solid rubber / polyurethane, tandem rollers

The right fork length depends on the size and shape of the loads you need to move. Longer forks can accommodate oversized load carriers or help you pick up several pallets at once, provided the truck’s capacity and the load arrangement allow it.

All the long fork pallet trucks in our range are suitable for processing extra-long pallets, Euro pallets crosswise and lengthways, or multiple pallets simultaneously.

Long fork pallet trucks are available in the following lengths:

Brand Available special fork lengths
Jungheinrich AM 22
  • 1207 mm
  • 1360 mm
  • 1600 mm
  • 1900 mm
  • 2400 mm
Jungheinrich AM 30
  • 1220 mm
  • 1600 mm
  • 1800 mm
  • 2100 mm
Ameise®
  • 1500 mm
  • 1800 mm
  • 2000 mm
  • 2500 mm

The Jungheinrich AM 22 series is also available with a non-standard fork width of up to 680 mm rather than the standard 520-540 mm. The wider spacing gives you more flexibility when positioning and handling pallets. Embossed markings on each model show which pallet positions it can accommodate.

2. Buy extra-long pallet trucks with the required load capacity

Load capacities vary by model, with options in our range for loads of up to 3500 kg. For example, the Jungheinrich AM 22 is available with a capacity of up to 2200 kg, the AM 30 up to 3000 kg and the Ameise® PTM 3.5 up to 3500 kg.

On some heavy-duty models, the load capacity stays the same across the available fork lengths. The load must still be evenly distributed and positioned around the specified load centre. Check the product details for the model’s limits and never exceed its rated capacity.

When selecting the correct model, it is also important to consider both average usage and peak load requirements. Find more information on this in our guide: Load capacity for industrial trucks – Dimensioning loads correctly.

3. Roller equipment and tyres for long pallet trucks

All our long fork pallet jacks are equipped with two steering wheels and tandem fork rollers, making it easier to transport loads on uneven surfaces or over speed bumps. In addition, they help distribute the load across the rollers, which means that loads can be moved with greater smoothness and stability. This also reduces the wear and tear of the individual rollers.

Depending on the model, you can choose from roller materials such as polyurethane (PU), nylon or solid rubber. The best option depends on your floor surface, load, noise requirements and working environment. Check each product’s specifications for details such as rolling resistance, temperature range and chemical resistance. We offer castors in the following materials:

Tyre material Polyurethane (PU) Nylon Solid rubber
Available for
  • Fork and swivel castors
  • Fork and swivel castors
  • Castors
Properties
  • Flexible and damage-resistant
  • Leaves no marks
  • Low wear
  • Shock-absorbing
  • Heavy-duty
  • Long service life
  • Oil and grease resistant
  • Abrasion-resistant
  • Non-chalking
  • Low wear
  • More prone to impact damage
  • Can create high surface pressure
  • Resistant to acids and alkalis
  • Damage- and shock-resistant
  • Good load distribution

  • High elasticity
  • May leave slight marks

  • Good grip on rough, uneven, damp, or smooth floors
Rolling resistance and operation
  • Low rolling resistance
  • Quiet operation
  • Low rolling resistance
  • Noisy operation
  • Higher rolling resistance
  • Smooth operation
Temperature resistance
  • -20 °C to 80 °C
  • -40 °C to 90 °C
  • -5 °C to 80 °C
Suitability
  • For hard and sensitive floors
  • Food and chemical industry
  • On smooth and even floors
  • Use with care on soft or pressure-sensitive floors (such as tiles)
  • For environments where noise is to be kept to a minimum
  • Applications needing special traction, e.g. on uneven floors, outdoors in damp conditions, or on ramps

4. Additional features for long fork pallet trucks

To make it both easier and more convenient to load, transport, and unload palletised and drive-under goods, some of our long fork jacks are equipped with additional practical features, including:

  • Quick lift: On compatible models, lighter loads of up to 120 kg can be lifted clear of the floor in three pump strokes. The maximum lift height is reached after five strokes. For heavier loads, the truck switches to its standard lift function.
  • Grease fittings: Selected Ameise® models have grease nipples to make lubrication easier. Some Jungheinrich models instead use maintenance-free bearings or lifetime-lubricated connections. Check the details for the model you are considering.
