Item number:
129644
META cantilever rack, single-sided, LC 150 kg, 3 uprights
With welded arms of different lengths
18 Working days
Free shipping from £50 (plus VAT)
Secure data protection
Personal purchasing advice
Technical details
META cantilever rack, single-sided, LC 150 kg, 3 uprights
Article number: 129644 | EAN/GTIN: 4026212275469
| Access options | one-sided |
| Assembly | Screw assembly |
| Axle distance | 1350 mm |
| Bay load max. | 900 kg |
| Bay type | Complete package |
| Brand | META |
| Effective depth | 500 mm |
| Exterior dimensions base unit | Nominal width + 46 mm / external dimension depth, one-sided = 590 mm |
| External dimension depth | 590 mm |
| External dimension height | 2000 mm |
| External dimension width | 2746 mm |
| Grid | 100 mm |
| Load per arm max. | 150 kg |
| Net weight | 70,1 kg |
| No. of cantilever arms per upright (incl. foot) | 7 |
| No. of levels | 7 |
| No. of uprights | 3 |
| Nominal depth | 500 mm |
| Nominal height | 2000 mm |
| Nominal width | 2700 mm |
| Place of manufacture | Made in Europe |
| Quality mark | RAL-RG 614/5 (cantilever shelves) |
| Rack type | Cantilever rack |
| Section | Professional |
| Support arm RAL colour | RAL 5010 enzianblau |
| Uprights RAL colour | RAL 5010 gentian blue |
| quality seal | Certified security |
Item description
META cantilever rack, single-sided, LC 150 kg, 3 uprights
Article number: 129644 | EAN/GTIN: 4026212275469
Do you regularly have to store long goods in the form of heavy pipes or beams? Then special racks are a great help. The META cantilever rack with a load capacity of 150 kg is ideal even with limited storage space.
- Cantilever rack for a space-saving position on the wall
- For the storing of long items, e.g. wooden strips or metal pipes
- With cantilever arms welded to the uprights in different lengths
- Integrated roll-off protection on all arms
- Available with different numbers of uprights
Loaded from only one side, the META cantilever rack is ideal for storing long and heavy parts up to 150 kg
Long goods, such as wood strips, metal pipes and over-long plate goods are safely lifted in the META cantilever rack with 7 levels. Since the rack has only one storage side, space-saving positioning is possible directly against the wall or on the rear wall of other racking. This makes it possible to optimally utilise the space available, even in small storage areas.
Quick and easy to install, the rack has cantilever arms of different lengths. These are welded to the uprights and each is equipped with roll-off protection for all pipe and roll-shaped products. The cantilever rack is available in different sizes as well as with a different number of uprights. On each level, the cantilever arms can be loaded with an evenly distributed load of 150 kg; the rack surface is sandblasted and powder-coated.
Store heavy long goods reliably and in a space-saving manner – order the META cantilever rack from us here.
Long goods, such as wood strips, metal pipes and over-long plate goods are safely lifted in the META cantilever rack with 7 levels. Since the rack has only one storage side, space-saving positioning is possible directly against the wall or on the rear wall of other racking. This makes it possible to optimally utilise the space available, even in small storage areas.
Quick and easy to install, the rack has cantilever arms of different lengths. These are welded to the uprights and each is equipped with roll-off protection for all pipe and roll-shaped products. The cantilever rack is available in different sizes as well as with a different number of uprights. On each level, the cantilever arms can be loaded with an evenly distributed load of 150 kg; the rack surface is sandblasted and powder-coated.
Store heavy long goods reliably and in a space-saving manner – order the META cantilever rack from us here.
Product Notes
Die Belastungen der Kragarme gelten bei gleichmäßiger Lastverteilung. Doppelseitige Ständer haben bei einseitiger Nutzung nur die halbe Ständerlast. Die in der Tabelle angegebene Tiefe ist die Nutztiefe des längsten Armes je Seite.
Our offer is aimed exclusively at commercial customers (entrepreneurs). In particular, the product is not intended for use by consumers.
