META cantilever rack, double-sided, LC 200 kg, 3 uprights
Space-saving storage of over-long and heavy individual parts
11 Working days
Free shipping from £50 (plus VAT)
Secure data protection
Personal purchasing advice
Technical details
META cantilever rack, double-sided, LC 200 kg, 3 uprights
Article number: 129640 | EAN/GTIN: 4026212275421
| Access options | double-sided |
| Assembly | Screw assembly |
| Bay load max. | 2000 kg |
| Bay type | Complete package |
| Brand | META |
| Depth | 1150 mm |
| Effective depth | 500 mm |
| Exterior dimensions base unit | Nominal width + 55 mm / external dimension depth, double-sided = 1.150 mm |
| Grid | 100 mm |
| Height | 2000 mm |
| Kragarm-Abstand | 1350 mm |
| Load per arm max. | 200 kg |
| Net weight | 126,87 kg |
| No. of cantilever arms per upright (incl. foot) | 12 |
| No. of levels | 6 |
| No. of uprights | 3 |
| Nominal width | 2700 mm |
| Place of manufacture | Made in Europe |
| Quality mark | RAL-RG 614/5 (cantilever shelves) |
| Rack type | Cantilever rack |
| Section | Professional |
| Support arm RAL colour | RAL 5010 enzianblau |
| Uprights RAL colour | RAL 5010 gentian blue |
| Width | 2755 mm |
| quality seal | Certified security |
Item description
META cantilever rack, double-sided, LC 200 kg, 3 uprights
Article number: 129640 | EAN/GTIN: 4026212275421
Cantilever racks are indispensable in any warehouse for the storage of load carriers, cross members and similarly shaped heavy objects. Of particular value is the high capacity offered by the double-sided versions with a load capacity of 200 kg.
- META cantilever rack, double-sided, ideal for the storage of long goods
- Already welded cantilever arms with identical arm lengths
- Integrated roll-off protection on all arms
- Version possible with 3 to 6 uprights
Cantilever rack for the secure storage of long goods
It is not always easy to accommodate long and heavy items in a warehouse. Although it may be possible to stack wooden beams or load carriers relatively easily in a recess, this is not the case for metal pipes or similar items. If you decide on a cantilever rack, future storage challenges will be made less complicated.
You can load the double-sided META cantilever rack with loads of up to 200 kg per load arm. In addition, the arms of equal length are equipped with integrated roll-off protection, enabling you to also store pipes or round bars without any worries. The cantilever rack is available in various sizes. This provides you with a flexible storage system, which you can adapt to the local conditions at any time.
Discover for yourself this flexible opportunity for storing long goods and order the double-sided cantilever rack from us here.
It is not always easy to accommodate long and heavy items in a warehouse. Although it may be possible to stack wooden beams or load carriers relatively easily in a recess, this is not the case for metal pipes or similar items. If you decide on a cantilever rack, future storage challenges will be made less complicated.
You can load the double-sided META cantilever rack with loads of up to 200 kg per load arm. In addition, the arms of equal length are equipped with integrated roll-off protection, enabling you to also store pipes or round bars without any worries. The cantilever rack is available in various sizes. This provides you with a flexible storage system, which you can adapt to the local conditions at any time.
Discover for yourself this flexible opportunity for storing long goods and order the double-sided cantilever rack from us here.
Product Notes
Die Belastungen der Kragarme gelten bei gleichmäßiger Lastverteilung. Doppelseitige Ständer haben bei einseitiger Nutzung nur die halbe Ständerlast. Die in der Tabelle angegebene Tiefe ist die Nutztiefe des längsten Armes je Seite.
Our offer is aimed exclusively at commercial customers (entrepreneurs). In particular, the product is not intended for use by consumers.
