Item number:
105419
META cantilever rack, AU, double-sided, LC 175 kg, height 2,500 mm
The add-on unit expands your existing racking with additional storage space
11 Working days
Free shipping from £50 (plus VAT)
Secure data protection
Personal purchasing advice
Technical details
META cantilever rack, AU, double-sided, LC 175 kg, height 2,500 mm
Article number: 105419 | EAN/GTIN: 4026212119404
| Access options | double-sided |
| Assembly | Screw assembly |
| Bay load max. | 2600 kg |
| Bay type | Extension module |
| Brand | META |
| Depth | 1220 mm |
| Effective depth | 500 mm |
| Exterior dimensions add-on unit | Axle distance + 64 mm / nominal depth + 220 mm |
| External dimension depth | 500 mm |
| External dimension height | 2500 mm |
| External dimension width | 1030 mm |
| Grid | 100 mm |
| Height | 2500 mm |
| Kragarm-Abstand | 1030 mm |
| Load per arm max. | 175 kg |
| Net weight | 58,21 kg |
| No. of cantilever arms per upright (incl. foot) | 10 |
| No. of levels | 5 |
| No. of uprights | 1 |
| Nominal depth | 500 mm |
| Nominal height | 2500 mm |
| Nominal width | 1000 mm |
| Place of manufacture | Made in Europe |
| Quality mark | RAL-RG 614/5 (cantilever shelves) |
| Rack type | Cantilever rack |
| Section | Professional |
| Support arm RAL colour | RAL 5010 enzianblau |
| Uprights RAL colour | RAL 5010 gentian blue |
| Width | 1030 mm |
| configurable | Yes |
| next fitting rack is base field | Yes |
| quality seal | Certified security |
Item description
META cantilever rack, AU, double-sided, LC 175 kg, height 2,500 mm
Article number: 105419 | EAN/GTIN: 4026212119404
Do you already have cantilever racks with the capacity of which you would like to increase? Then the META cantilever rack add-on units are just what you need. The add-on units are installed by means of simple boltless assembly and will offer you more storage space in no time.
- Double-sided META cantilever rack add-on unit for existing cantilever racks
- Maximum load per arm 220 kg
- Ideal for the storage of long and heavy parts
- Quick, simple assembly via boltless assembly and locking screws
Add-on unit for double-sided cantilever rack for flexible, individual storage systems
The META cantilever racks are ideally suited to the storage of goods such as metal pipes, poles or plate goods. Are stored goods a major part of your company’s operation and do you want to expand the storage area? Then the appropriate cantilever rack add-on unit will help you. Use your existing META cantilever rack and simply expand it.
Just like the META base unit, the META add-on unit is also available in various sizes and with different load capacities. So you will find the appropriate add-on unit for each base unit. In particular, the double-sided version offers you lots of extra storage space. You can quickly and easily attach the add-on unit by means of the boltless assembly system and secure it with the appropriate locking screws – and there you have your expanded storage area at your disposal. The cantilever arms have the same arm length and are all height-adjustable in increments of 100 mm.
Discover the options and expand your cantilever racking system for even more space-saving storage.
The META cantilever racks are ideally suited to the storage of goods such as metal pipes, poles or plate goods. Are stored goods a major part of your company’s operation and do you want to expand the storage area? Then the appropriate cantilever rack add-on unit will help you. Use your existing META cantilever rack and simply expand it.
Just like the META base unit, the META add-on unit is also available in various sizes and with different load capacities. So you will find the appropriate add-on unit for each base unit. In particular, the double-sided version offers you lots of extra storage space. You can quickly and easily attach the add-on unit by means of the boltless assembly system and secure it with the appropriate locking screws – and there you have your expanded storage area at your disposal. The cantilever arms have the same arm length and are all height-adjustable in increments of 100 mm.
Discover the options and expand your cantilever racking system for even more space-saving storage.
Product Notes
Regale mit Höhen-Tiefen-Verhältnis ≥ 5:1 gegen Kippen sichern. Die Belastungen der Kragarme gelten bei gleichmäßiger Lastverteilung. Doppelseitige Ständer haben bei einseitiger Nutzung nur die halbe Ständerlast. Die in der Tabelle angegebene Tiefe ist die Nutztiefe der Arme je Seite.
