Item number:
144018
EdmoLift® C Series scissor lift table, LC 500 kg, platform 900 x 600 mm
Maximale Sicherheit und Stabilität für den industriellen Einsatz
Current variant:
Capacity:
Platform depth:
Platform width:
Power:
-
Free shipping from £50 (plus VAT)
-
Secure data protection
-
Personal purchasing advice
Technical details
EdmoLift® C Series scissor lift table, LC 500 kg, platform 900 x 600 mm
Article number: 144018 | EAN/GTIN: 4055091077772 Main category: Single scissor lift tables
Loading...
| Brand |
EdmoLift® |
| Capacity |
500 kg |
| Cylinder diameter |
40 mm |
| Delivery |
fully assembled |
| Frequency |
50 Hz |
| Lift |
600 mm |
| Lift cycles max. |
30 Per day |
| Lift function |
electro-hydraulic |
| Lift range |
160 - 760 mm |
| Lift speed with/without load |
50 mm/s |
| Lift time |
12 s |
| Lowering speed with/without load |
150 mm/s |
| Material |
Steel |
| Net weight |
110 kg |
| No. of cylinders |
1 |
| Operator type |
Deadman switch |
| Platform depth |
900 mm |
| Platform type |
closed |
| Platform width |
600 mm |
| Power |
0,37 kW |
| Power supply |
Three-phase current |
| RAL colour |
RAL 2010 signal orange RAL 5002 ultramarine blue |
| Scissors type |
Single scissors |
| Section |
Professional |
| Surface |
powder-coated |
| Voltage |
400 V |
Item description
EdmoLift® C Series scissor lift table, LC 500 kg, platform 900 x 600 mm
Article number: 144018 | EAN/GTIN: 4055091077772
Der EdmoLift® Scheren-Hubtisch der C-Serie kombiniert robuste Bauweise mit modernster Hydrauliktechnik und ist damit eine zuverlässige Lösung für anspruchsvolle Anwendungen. Seine hochwertige Konstruktion aus Baustahl ST37 gewährleistet Langlebigkeit selbst im Dauereinsatz. Eine Pulverbeschichtung schützt die Oberfläche zusätzlich vor Verschleiß und Umwelteinflüssen. Durch die integrierte Steuereinheit UC60 in Plug-and-Play-Ausführung lässt sich der Hubtisch einfach und sicher in bestehende Arbeitsabläufe integrieren.
- Robust EdmoLift® C series hydraulic lift table in ST37 structural steel
- High durability due to powder coating
- Including electronic control unit UC60 (Plug-and-Play version)
- Control device with deadman switch
- 3 m connecting cable with CEE-plug
Hydraulic EdmoLift® C Series scissor lift table for ergonomic material feeding at the workstation
If heavy loads must be moved in an occupational area, energy-saving working methods are particularly important. They guarantee that you will remain fit and healthy in the long term. So carry out your everyday work in a pleasant, upright position at a lift platform, which can be hydraulically moved to any desired height.
The load-bearing components of this lifting device are made from robust structural steel, which is protected by a powder coating. Thanks to this method, the robust hydraulic lift platform is able to meet all the requirements of the industrial environment. The platform is raised to the desired height using the electric drive of the single scissor. After loading, it can slowly be lowered hydraulically by the scissor lift platform. Since the lift platforms are delivered fully assembled, including a 3 m connection cable and plug, they can be used immediately after delivery in your company.
Simplify your material loading and order EdmoLift® C series hydraulic lift tables with single scissor for your support.
If heavy loads must be moved in an occupational area, energy-saving working methods are particularly important. They guarantee that you will remain fit and healthy in the long term. So carry out your everyday work in a pleasant, upright position at a lift platform, which can be hydraulically moved to any desired height.
The load-bearing components of this lifting device are made from robust structural steel, which is protected by a powder coating. Thanks to this method, the robust hydraulic lift platform is able to meet all the requirements of the industrial environment. The platform is raised to the desired height using the electric drive of the single scissor. After loading, it can slowly be lowered hydraulically by the scissor lift platform. Since the lift platforms are delivered fully assembled, including a 3 m connection cable and plug, they can be used immediately after delivery in your company.
Simplify your material loading and order EdmoLift® C series hydraulic lift tables with single scissor for your support.
Product Notes
Our offer is aimed exclusively at commercial customers (entrepreneurs). In particular, the product is not intended for use by consumers.
Warning and safety information
Die angegebene Tragkraft gilt nur bei gleichmäßig verteilter Last. Für eine ungleichmäßig verteilte oder rollende Last muss gegebenenfalls ein anderer Hubtisch gewählt werden. Bitte nehmen Sie hierzu Kontakt zu unserer Fachberatung auf.
