Topseller
Item number:
170216
Scissor lift table, single scissor, capacity 1,000 kg, platform dimensions 1,300 x 800 mm, Ameise®
Electric lifting and lowering for effective working at an ergonomic height
-
Free shipping from £50 (plus VAT)
-
Secure data protection
-
Personal purchasing advice
Technical details
Scissor lift table, single scissor, capacity 1,000 kg, platform dimensions 1,300 x 800 mm, Ameise®
Article number: 170216 | EAN/GTIN: 4055091127507
| Amperage |
16 A |
| Brand |
Ameise® |
| Capacity |
1000 kg |
| Delivery |
fully assembled |
| Frequency |
50 Hz |
| Hydraulic oil quantity |
1.5 l |
| Hydraulic oil type |
Mineral oil |
| Hydraulic oil viscosity acc. to ISO-VG |
32 |
| Lift |
820 mm |
| Lift cycles max. |
10 Per hour |
| Lift function |
electro-hydraulic |
| Lift range |
190 - 1010 mm |
| Lift speed with/without load |
40 mm/s |
| Lift time |
25 s |
| Lowering speed with/without load |
35 mm/s |
| Material |
Steel |
| Net weight |
180 kg |
| No. of cylinders |
1 |
| Operator type |
Manual manual |
| Platform depth |
1300 mm |
| Platform height |
65 mm |
| Platform type |
closed |
| Platform width |
800 mm |
| Power |
0,75 kW |
| Power supply |
Three-phase current |
| RAL colour |
RAL 5018 turquoise blue |
| Scissors type |
Single scissors |
| Section |
Performance |
| Surface |
powder-coated |
| Voltage |
380 V |
Item description
Scissor lift table, single scissor, capacity 1,000 kg, platform dimensions 1,300 x 800 mm, Ameise®
Article number: 170216 | EAN/GTIN: 4055091127507
The stationary, single-scissor Ameise® lift table can be attached to the floor or embedded in the ground. The platform is raised and lowered with electric power, making ergonomic working even more comfortable and productive.
- Electric lifting and lowering of the platform
- Fully variable hydraulic height adjustment
- External control unit with pushbuttons, key switch and emergency disconnect
- High-quality pump with safety valve for long service life
- Maintenance-friendly design
Ameise® scissor lift table with electrically operated lift function for highly ergonomic working
The Ameise® scissor lift table impresses with its robust and proven quality and is designed to withstand the rigours of everyday use. The stationary lift table can be attached to the floor or embedded in the ground. The fully variable, hydraulic height adjustment of the platform is operated via convenient push-buttons. You can thus easily raise the load on the scissor lift table to your ideal, ergonomic height for fatigue-free working. The control unit is connected to the lift table via a 2.65 m cable for safe operation from any distance using the push-buttons with key switch and emergency disconnect. The high-quality hydraulic pump with safety valve ensures a long service life and protects against overloading.
Inspection supports prevent accidental lowering of the lift table during servicing, with additional safety provided by the protective frame.
The tough, durable construction comprises a powder-coated platform made from sheet steel, a subframe made from welded angle sections and robust scissor bracing. The Ameise® scissor lift table is available with different capacities.
The Ameise® single scissor lift table represents an ideal solution with regard to ergonomics, functionality and safety. Order the correct version for your needs from our shop.
The Ameise® scissor lift table impresses with its robust and proven quality and is designed to withstand the rigours of everyday use. The stationary lift table can be attached to the floor or embedded in the ground. The fully variable, hydraulic height adjustment of the platform is operated via convenient push-buttons. You can thus easily raise the load on the scissor lift table to your ideal, ergonomic height for fatigue-free working. The control unit is connected to the lift table via a 2.65 m cable for safe operation from any distance using the push-buttons with key switch and emergency disconnect. The high-quality hydraulic pump with safety valve ensures a long service life and protects against overloading.
Inspection supports prevent accidental lowering of the lift table during servicing, with additional safety provided by the protective frame.
The tough, durable construction comprises a powder-coated platform made from sheet steel, a subframe made from welded angle sections and robust scissor bracing. The Ameise® scissor lift table is available with different capacities.
The Ameise® single scissor lift table represents an ideal solution with regard to ergonomics, functionality and safety. Order the correct version for your needs from our shop.
Product Notes
Our offer is aimed exclusively at commercial customers (entrepreneurs). In particular, the product is not intended for use by consumers.
Warning and safety information
The specified capacity applies only to an evenly distributed load. For unevenly distributed or rolling loads, a different lift table may need to be selected. Please contact our specialist advisers for further information.
